AUDIO INSERTERS (Embedders)
DAI-4206:
3G/HD/SD-SDI Audio Inserter.
Standard 75 Ohm 3G/HD/SD-SDI video input and outputs.
Supports all video line and frame rate standards.
Inserts audio signals into 2 selectable groups.
Eight high quality analogue audio inputs; or
Four 110 Ohm balanced AES inputs.
20 bit and 24 bit audio supported.
Z, C, U data preserved (non re-sampled mode.
Select between AES or Analogue audio inputs.
AES resampling.
Ability to replace existing embedded audio.
Indicators for presence of SDI & audio inputs.
External alarm for loss of carrier.
Selectable SDI generator outputs colour black test signal on loss of SDI input.
Selectable tone generator inserts audio test signals within set audio groups.
Cascadable - Two SDI outputs for connection to additional units.
Simple Network Management Protocol (SNMP) capable.
AUDIO EXTRACTORS (De-Embedders)
DAX-4206:
3G/HD/SD-SDI Audio Extractor.
Standard 75 Ohm 3G/HD/SD-SDI video input and outputs.
Supports all video line and frame rate standards.
Extracts audio signals from 2 selectable groups.
Eight high quality analogue audio outputs.
Four 110 Ohm balanced AES outputs.
Indicators for presence of SDI input type & audio within selected groups.
External alarms for loss of carrier & audio.
Selectable tone generator on audio outputs allow for audio test alignment signals.
Cascadable - Two SDI outputs for connection to additional units.
Simple Network Management Protocol (SNMP) capable.
